General Pump EP1813S17 EP Series Solid Shaft Triplex Pump, 2900 PSI, 4.2 GPM, 1750 RPM, 24mm Shaft

The General Pump EP1813S17 is an EP Series triplex plunger pump with a 24mm solid shaft for belt or gear drive at 1,750 RPM. It delivers 4.2 GPM at up to 2,900 PSI with a forged brass manifold, solid ceramic plungers with dual guide system and a dual lip oil seal. It replaces the TX1813S17.

Key Features

• Triplex plunger pump
• New Forged brass manifold
• New plunger guide bushing (patent pending)
• Solid ceramic plungers with dual guide system
• New dual diameter plunger guide
• New optimized outlet valves
• New dual lip oil seal
• Solid Shaft for Belt or Gear Drive
• Dimensions – Nominal: 9.5” x 8.38” x 5.1”
• Replaces TX1813S17

Specifications

Note: High Pressure Systems require a primary pressure regulating device (i.e. regulator, unloader) and a secondary pressure relief device (i.e. pop-off valve, relief valve). Failure to install such relief devices properly could result in personal injury or damage to pump or property. GP and PRI Industries do not assume any liability or responsibility for the operation of the user’s high pressure system.

Note: Item for sale is PUMP ONLY as shown in picture and does not include unloader which is required for proper operation

Frequently Asked Questions

What does it replace?

General Pump TX1813S17.

How is it driven?

By belt or gear drive through its 24mm (0.945") solid shaft at up to 1,750 RPM.

What horsepower is required?

8.3 EBHP.

What are the port threads?

1/2"-14 BSP female inlet and 3/8"-19 BSP female discharge.

Is an unloader included?

No. It is pump only.
