General Pump EZ2555E Triplex Plunger Pump, 2500 PSI, 5.5 GPM, 1750 RPM, NEMA 184C, 1-1/8" Hollow Shaft

Name: General Pump EZ2555E Triplex Plunger Pump, 2500 PSI, 5.5 GPM, 1750 RPM, NEMA 184C, 1-1/8" Hollow Shaft
Brand: General Pump
SKU: EZ2555E
Price: 725.01 USD
Availability: OutOfStock

Vendor: General Pump Type: Plunger Pump

$725.01

Shipping calculated at checkout.

Out of Stock

Payment & Security

Your payment is secure. We don’t store or see your card details.

View Full Details

The General Pump EZ2555E is an industrial triplex plunger pump that delivers 5.5 GPM at up to 2,500 PSI. It mounts directly to NEMA 184C electric motors at 1,750 RPM through a 1-1/8" hollow shaft, and its forged brass head and solid ceramic plungers suit car washes, washdown systems and high-volume cleaning.

Key Features

Triplex Plunger Pump
Direct Drive with Electric Flange NEMA 184C
Forged brass head & valve covers
Solid ceramic plungers

Specifications

Brand	General Pump
Manufacturer Part Number	EZ2555E
Max. Volume	5.5 GPM
Max. Discharge Pressure	2,500 PSI
Max. Pump Speed	1750 RPM
Shaft Diameter	1 1/8” Hollow
Max. Horsepower Requirements	9.4 EBHP
Max. Fluid Temp.	165º degrees F.
Inlet Ports (2)	1/2″ BSP
Discharge Ports (2)	3/8″ BSP
Drive Side	Standard right
Weight	18.5 lb.

Frequently Asked Questions

What horsepower motor does it need?

9.4 EBHP.

What motor frame does it fit?

NEMA 184C motors with a 1-1/8" shaft.

What are the port threads?

Two 1/2" BSP inlets and two 3/8" BSP discharge ports.

What is the maximum water temperature?

165°F.

How much does it weigh?

About 18.5 lbs.

Product Specifications

Specification Name	Specification Value
Color pattern	Gold
Power source	AC-powered
